Optical System | Infinity achromatic correction optional system and common optical system |
Viewing Head | Articulated free binocular or trinocular head,30"inclined,interpupillary distance 50-75mm |
Eyepiece | PL10X/23mm 30mm PL10X/23mm high eyepoint eyepiece,diopter adjustment±5,tube |
Objective | Plan achromatic objectives4X,10X,40X,100X |
Nosepiece | Backward quintuple or quadruple objective nosepiece |
Condenser | Abbe condenser set |
Stage | 220x148mm X-axis low hand position double mechanical stage(steel wire transmission): 76x50mm,precision 0.1mm,damped double slide clamp |
Focusing System | Coaxial coarse and fine focus knobs,precision 0.002mm |
Illumination | 3W LED lamp with Kohler illumination system |
LCD | 8"color LCD |
objectives | Achromatic objective 4X,10X,20X,40X,60X,100X |
Plan objectives 20X,60X |
Infinity Plan Achromatic objective 4X,10X,20X,40X,60X,100X |
