Throughput | 60 samples/hour |
Principle | Tri-angle laser scattering and sheath flow for WBC differentiation andc counting, impedance for RBC and PLT, cyanide-free method for HGB |
Channels | 2 |
Aperture diameter | RBC/PLT chamber: 70um |
Parameters | 25+4 parameters: WBC, Lym%, Mon%, Neu%, Bas%, Eos%, Lym#,Mon#, Neu#, Eos#, Bas#, RBC, HGB, |
HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PDW, PCT, P-LCR, P-LCC, LIC%, LIC#, |
ALY%, ALY# |
Histograms | 4 scatter-grams, 2 histograms(including RBC, PLT histograms) |
HGB lamp | LED530nm |
Sample volume | Whole blood mode: 20ul, Pre-diluted mode: 20ul |
Calibration | Manual, auto and fresh blood calibration |
Counting modes | Whole blood, capillary whole blood, prediluted |
Print | Auto print, manual print |
LIS | Support LIS |
Reagent | Standard: Diluent: 20L, DIFF Lyse: 500ml, LH Lyse: 100mL |
Cleanser | Standard: Probe cleanser: 50ml |
Input | 10.4 inch touch screen, keyboard, mouse |
Output | Internal printer, support external printer |
Printer paper | 57×35mm |
Interface | RS232 port, 4 USB ports, 1 network ports |
Storage | 50,000 results with histogram |
Dimension | 430 x 350 x 435mm |
Blockage clear | High voltage, high pressure flush |
Net weight | 28KG |
Work temperature | 10-30°C |
Power requirement | 100~240 AC, 50/60Hz, 300VA |
Relative humidity | ≤85% |
Atmospheric pressure | 70.0kPa-106.0kPa |
Carry-over rate | Parameter | CV |
WBC | ≤ 0.5% |
RBC | ≤ 0.5% |
HGB | ≤ 0.6% |
PLT | ≤ 1.5% |
Background | Parameter | Background |
WBC | ≤ 0.2×109/L |
RBC | ≤ 0.02×1012/L |
HGB | ≤ 1 g/L |
HCT | ≤ 0.5% |
PLT | ≤10×109/L |
Precision | Parameter | Whole blood sample CV (CV/absolute deviation d) | Pre-diluted sample CV (CV/absolute deviation d) | Measurement range |
WBC | ≤2.0% | ≤4.0% | (4.00~15.00)*109/L |
RBC | ≤1.5% | ≤3.0% | (3.50~6.00)*1012/L |
HGB | ≤1.5% | ≤3.0% | (110~180)g/L |
PLT | ≤4.0% | ≤8.0% | (150~500)*109/L |
Linearity | Parameter | Linearity Range | Linearity(Whole blood) | Linearity(Pre-diluted) |
WBC | (0.00~100.00)*109/L | ±5% | ±6% |
RBC | (0.00~8.00)*1012/L | ±5% | ±10% |
HGB | (0~250)g/L | ±2% | ±4% |
PLT | (0~1000)*109/L | ±8% | ±16% |
