MS-D30 Digital Panoramic X-ray Machine
Imaging System
Adopt Thales Flat Panel Detector High Resolution,small distortion,Brightness Uniformity Effectve size:12cmX15cm flat panel detector View dimension:φ80X90 mm Display Resolution:1280X1024 Rotation angle:200° Rotation time:14S X-ray exposure time:4S Scanning quantity:200 frames
Great Quality Images
Adopt 3D reconstruction algorithm.
Transfer original 2D sequence images to 3D volumetric images,could provide sharp sectional images at different angle and position.
Extract sharp oral panoramic images from 3D volumetric images.
Item | MS-D30 |
Output Power | 1.38kw |
Tube voltage | 60-92 kV |
Tube Current | 1-15 mA |
Tube focus | 0.5mm |
Information Display | KV,MA,lifting position information,body features, laser lights indication and positioning |
Application | oral and maxillofacial surgery,orthognathic surgery, implant surgery,Endodontics surgery, temporal-mandibular joint surgery |
MS-D30 Digital Panoramic X-ray Machine
