MS-S420 Infusion Syringe Pump

Injection Mode

Constant rate, time/volume mode, drug weight mode,

micro-mode, programmable mode, drug library mode

Occlusion

Pressure

8 level adjustable，20Kpa-150Kpa，dynamically pressure

value display.

Syringe Size

5ml、10ml、20ml、30ml、50/60ml，auto-recognition

Alarm

Finished,near finished,near empty, empty, occlusion,

Syringe disconnected,no operation, parameter error,

syringe error, low battery, battery lost, battery ran out, AC power lost, abnormal injection, communication

error,finished! KVO.

Flow Rate

5ml：0.10ml/h-60.00ml/h 10ml：0.10ml/h-300.00ml/h

20ml：0.10ml/h-400.00ml/h 30ml：0.10ml/h-600.00ml/h

50/60ml：0.10ml/h-1200.00ml/h

Syringe

Management

Preset 20 syringe brands, can add or edit the brand,

Increment

0.01ml/h

Display

5.0’TFT color LCD, 10 level brightness adjustable

Preset Time

1s～99hr59min59s

Pressure Release

Function

Pressure release function after occlusion

Parameter

Changed during

Injection

Support change of VTBI, flow rate during injection

Power Supply

AC Power：100V-240V，50/60Hz，≦45W
